Pulley Cord 3 Core Cloth Covered Flex 120V

USD $2.82USD $3.52 Per foot

  • Operating temperature: +220°F maximum outer insulation temperature
  • Operating Voltage: 300V
  • Current Rating: 6A
  • Cores: 3
  • Cross Sectional Area: 18AWG
  • Multi-stranded annealed copper.
  • Insulation: Double insulated PVC/PVC
  • Insulation Colors: black, white, green.
  • Braiding Material: Poly cloth.
  • Average Diameter: 0.27″
  • Static suspension load: 8.8lb Max.
  • UL listing: E189672
Shipping Weight: 0.05lbs
Product Price

Warranty: 1 Year

Cut Sheet PDF

Product Description

Pulley Cord 3 Core Cloth Covered Flex 120V with active, neutral and earth wires in a round outer sheath.

A wide variety of colors are available to contrast or compliment your decor.
Custom colors and patterns are available to order, subject to minimum order quantities.

This cable is constructed utilizing UL recognized style STP cores with a secondary reinforcing PVC jacket (double insulated). A decorative braid is applied over. This cable has also been carefully designed to provide a minimal overall diameter, enabling it to pass easily through grommets and tubes.

Applications: Lighting pendants, table and floor lamps, rise and fall pendants.

Please note: Lengths ordered are supplied as one continuous piece, ie add to cart “6”  and you will receive a single, continuous 6ft length.

Operating temperature: +220°F maximum outer insulation temperature
Operating Voltage: 300V
Current Rating: 6A
Cores: 3
Cross Sectional Area: 18AWG
Multi-stranded annealed copper.
Insulation: Double insulated PVC/PVC
Insulation Colors: black, white, green.
Braiding Material: Poly cloth.
Average Diameter: 0.27″
Static suspension load: 8.8lb Max.
UL listing: E189672
